- 4CF 4F Corner Radius for High Feed Rate
- Features
- Reduced roughing time with high-speed cutting
- Suitable for roughing and semi-roughing at higher feed rate
- For Dry cutting and Wet cutting
- Tolerance
Cutting Dia. D≤6: 0/-0.01
D>6: 0/-0.015Corner Radius ±0.01
Recommended workpiece Material
| Carbon Steel/Alloy Steel(up to 350 HB) | Stainless Steel(up to 240 HB) | Cast lron(up to 260 HB) | Prehardened Steel(up to 50 HRc) | Hardened Steel(45 to 55 HRc) | Super Hardened Steel(55 to 68 HRc) | Titanium Alloy |
Copper Alloy |
Aluminum Alloy |
Resin & Plastics |
Graphite |
|---|---|---|---|---|---|---|---|---|---|---|
| ○ | △ | ○ | ○ | ◎ | ○ | ○ | △ |
가로로 스크롤하세요
(Unit: mm)
|
EDP No.
|
Cutting Dia X Corner R
d X CR |
Length of Cut
L1 |
Length of Reach
L2 |
Overall Length
L |
Shank Dia
D |
|---|---|---|---|---|---|
| 4CF 400 R100 60 | 4.0 X R1.0 | 4 | 12 | 60 | 6 |
| 4CF 600 R100 60 | 6.0 X R1.0 | 9 | 16 | 60 | 6 |
| 4CF 800 R100 65 | 8.0 X R1.0 | 12 | 25 | 65 | 8 |
| 4CF 1000 R200 70 | 10.0 X R2.0 | 15 | 25 | 70 | 10 |
| 4CF 1000 R200 100 | 10.0 X R2.0 | 15 | 30 | 100 | 10 |
| 4CF 1200 R200 70 | 12.0 X R2.0 | 18 | 30 | 70 | 12 |
| 4CF 1200 R200 100 | 12.0 X R2.0 | 18 | 35 | 100 | 12 |
